3 1/2 digits large LCD display with maximum reading of 1999

Versatility of use with AC/DC voltage and resistance measurement

Data hold for easy reading

Plug-in insulation tester adapter 500VCD(optional)

Audible continuity

Low power indication

Technical Specifications

Function

Range

Accuracy

DC Voltage

1000V

±(0.5%+1dgt)

AC Voltage

750V

±(1.2%+4dgt)

AC Current

200A-1000A

±(2.5%+5dgt)

Resistance

20MΩ-2000MΩ

±(1.0%+2dgt)

Continuity Buzzer

Yes

Display Hold

Yes

Power Supply

9V Battery 6F22

Maximum Display

1999

Display Size

14×47mm

Product Net Weight

350g

Products Size

230×70×37mm

Clamp color available

Red, Orange, Bright Red, Dark Green

Standard Accessories

Test Lead, Battery, Manual, Holster
