Description:
VP Series (1 stage)
|
Part No. |
Voltage
V/Hz |
Capacity
CFM |
Vacuum
Pa/Microns |
Motor
Power
(HP) |
Motor
Speed
(RPM) |
Intake
Fitting
(inch) |
Dimension
(mm) |
Weight
(kg) |
Oil
Capacity
(ml) |
|
VP-0.5A |
220V/50HZ
110V/60HZ |
1.00
1.20 |
10/75
10/75 |
1/6
1/6 |
1440
1720 |
1/4 SAE
1/4 SAE |
240×115×230
240×115×230 |
6
6 |
160
160 |
|
VP-1A |
220V/50HZ
110V/60HZ |
2.00
2.40 |
10/75
10/75 |
1/6
1/6 |
1440
1720 |
1/4 SAE
1/4 SAE |
249×121×230
249×121×230 |
7.2
7.2 |
250
250 |
|
VP-1S |
220V/50HZ
110V/60HZ |
2.00
2.50 |
5/35
5/35 |
1/6
1/6 |
2800
3360 |
1/4 SAE
1/4 SAE |
246×105×200
246×105×200 |
4.00
4.00 |
150
150 |
|
VP-1.5A |
220V/50HZ
110V/60HZ |
3.00
3.60 |
10/75
10/75 |
1/4
1/4 |
1440
1720 |
1/4 SAE
1/4 SAE |
249×121×230
249×121×230 |
7.40
7.40 |
200
200 |
|
VP-2A |
220V/50HZ
110V/60HZ |
4.00
4.50 |
10/75
10/75 |
1/3
1/3 |
1440
1720 |
1/4 SAE
1/4 SAE |
315×125×240
315×125×240 |
8.80
8.80 |
250
250 |
|
VP-3A |
220V/50HZ
110V/60HZ |
5.50
6.60 |
10/75
10/75 |
1/2
1/2 |
1440
1720 |
1/4 SAE
1/4 SAE |
340×135×260
340×135×260 |
9.80
9.80 |
320
320 |
|
VP-4A |
220V/50HZ
110V/60HZ |
8.00
9.00 |
10/75
10/75 |
1/2
1/2 |
1440
1720 |
1/4 SAE
1/4 SAE |
390×145×280
390×145×280 |
15.50
15.50 |
700
700 |
2VP Series（2 stage）
|
Part No. |
Voltage V/Hz |
Capacity CFM |
Vacuum Pa/Microns |
Motor Power
(HP) |
Motor Speed (RPM) |
Intake Fitting (inch) |
Dimension
(mm) |
Weight (kg) |
Oil Capacity(ml) |
|
2VP-0.5C |
220V/50HZ
110V/60HZ |
1.00
1.20 |
5×10-1/25
5×10-1/25 |
1/4
1/4 |
1440
1720 |
1/4 SAE
1/4 SAE |
249×121×230
249×121×230 |
7.00
7.00 |
200
200 |
|
2VP-1C |
220V/50HZ
110V/60HZ |
2.00
2.50 |
5×10-1/25
5×10-1/25 |
1/3
1/3 |
1440
1720 |
1/4 SAE
1/4SAE |
315×125×240
315×125×240 |
9.00
9.00 |
250
250 |
|
2VP-2C |
220V/50HZ
110V/60HZ |
4.00
5.00 |
5×10-1/25
5×10-1/25 |
1/2
1/2 |
1440
1720 |
1/4SAE
1/4 SAE |
340×1135×260
340×135×260 |
10.00
10.00 |
280
280 |
|
2VP-3C |
220V/50HZ
110V/60HZ |
6.00
7.00 |
5×10-1/25
5×10-1/25 |
3/4
3/4 |
1440
1720 |
1/4 SAE
1/4SAE |
390×145×280
390×145×280 |
16.00
16.00 |
600
600 |
|
2VP-4C |
220V/50HZ
110V/60HZ |
8.00
9.00 |
5×10-1/25
5×10-1/25 |
3/4
3/4 |
1440
1720 |
1/4 SAE
1/4 SAE |
425×155×280
425×155×280 |
17.00
17.00 |
650
650 |
|
2VP-1S |
220V/50HZ
110V/60HZ |
2.00
2.50 |
3×10-1/20
3×10-1/20 |
1/4
1/4 |
2800
3360 |
1/4 SAE
1/4 SAE |
246×105×200
246×105×200 |
5.30
5.30 |
150
150 |
|
2VP-2S |
220V/50HZ
110V/60HZ |
4.00
5.00 |
5×10-1/50
5×10-1/50 |
1/3
1/3 |
2880
3360 |
1/4 SAE
1/4SAE |
337.5×134×225
337.5×134×225 |
13.10
13.10 |
250
250 |
*2VP-1S, 2VP-2S are lighter and faster than other items.
|
